R5F100FEAFP#10

Name: R5F100FEAFP#10
Brand: Jinjiana Electronic Co.,Ltd.
Availability: InStock

Buy R5F100FEAFP#10

R5F100FEAFP Overview

Ultra-Low Power Technology

• 1.6 V to 5.5 V operation from a single supply

• Stop (RAM retained): 0.23 µA, (LVD enabled): 0.31 µA

• Halt (RTC + LVD): 0.57 µA

• Snooze: 0.70 mA (UART), 1.20 mA (ADC)

• Operating: 66 µA/MHz

16-bit RL78 CPU Core

• Delivers 41 DMIPS at maximum operating frequency of 32 MHz

• Instruction Execution: 86% of instructions can be executed in 1 to 2 clock cycles

• CISC Architecture (Harvard) with 3-stage pipeline

• Multiply Signed & Unsigned: 16 x 16 to 32-bit result in

1 clock cycle

• MAC: 16 x 16 to 32-bit result in 2 clock cycles

• 16-bit barrel shifter for shift & rotate in 1 clock cycle

• 1-wire on-chip debug function

Technical Data Of R5F100FEAFP

Flash	Data	RAM	RL78/G13
ROM	flash	RAM	20 pins	24 pins	25 pins	30 pins	32 pins	36 pins
128	8 KB	12	−	−	−	R5F100AG	R5F100BG	R5F100CG
KB	−	KB	−	−	−	R5F101AG	R5F101BG	R5F101CG
96	8 KB	8 KB	−	−	−	R5F100AF	R5F100BF	R5F100CF
KB	−	8 KB	−	−	−	R5F101AF	R5F101BF	R5F101CF
64	4 KB	4 KB	R5F1006E	R5F1007E	R5F1008E	R5F100AE	R5F100BE	R5F100CE
KB	−	Note 1	R5F1016E	R5F1017E	R5F1018E	R5F101AE	R5F101BE	R5F101CE
48	4 KB	3 KB	R5F1006D	R5F1007D	R5F1008D	R5F100AD	R5F100BD	R5F100CD
KB	−	3 KB	R5F1016D	R5F1017D	R5F1018D	R5F101AD	R5F101BD	R5F101CD
32	4 KB	2 KB	R5F1006C	R5F1007C	R5F1008C	R5F100AC	R5F100BC	R5F100CC
KB	−	2 KB	R5F1016C	R5F1017C	R5F1018C	R5F101AC	R5F101BC	R5F101CC
16	4 KB	2 KB	R5F1006A	R5F1007A	R5F1008A	R5F100AA	R5F100BA	R5F100CA
KB	−	2 KB	R5F1016A	R5F1017A	R5F1018A	R5F101AA	R5F101BA	R5F101CA

Flash	Data	RAM	RL78/G13
ROM	flash	RAM	40 pins	44 pins	48 pins	52 pins	64 pins	80 pins	100 pins	128 pins
512	8 KB	32 KB	−	R5F100FL	R5F100GL	R5F100JL	R5F100LL	R5F100ML	R5F100PL	R5F100SL
KB	−	Note 3	−	R5F101FL	R5F101GL	R5F101JL	R5F101LL	R5F101ML	R5F101PL	R5F101SL
384	8 KB	24 KB	−	R5F100FK	R5F100GK	R5F100JK	R5F100LK	R5F100MK	R5F100PK	R5F100SK
KB	−	24 KB	−	R5F101FK	R5F101GK	R5F101JK	R5F101LK	R5F101MK	R5F101PK	R5F101SK
256	8 KB	20 KB	−	R5F100FJ	R5F100GJ	R5F100JJ	R5F100LJ	R5F100MJ	R5F100PJ	R5F100SJ
KB	−	Note 2	−	R5F101FJ	R5F101GJ	R5F101JJ	R5F101LJ	R5F101MJ	R5F101PJ	R5F101SJ
192	8 KB	16 KB	R5F100EH	R5F100FH	R5F100GH	R5F100JH	R5F100LH	R5F100MH	R5F100PH	R5F100SH
KB	−	16 KB	R5F101EH	R5F101FH	R5F101GH	R5F101JH	R5F101LH	R5F101MH	R5F101PH	R5F101SH
128	8 KB	12 KB	R5F100EG	R5F100FG	R5F100GG	R5F100JG	R5F100LG	R5F100MG	R5F100PG	−
KB	−	12 KB	R5F101EG	R5F101FG	R5F101GG	R5F101JG	R5F101LG	R5F101MG	R5F101PG	−
96	8 KB	8 KB	R5F100EF	R5F100FF	R5F100GF	R5F100JF	R5F100LF	R5F100MF	R5F100PF	−
KB	−	8 KB	R5F101EF	R5F101FF	R5F101GF	R5F101JF	R5F101LF	R5F101MF	R5F101PF	−
64	4 KB	4 KB	R5F100EE	R5F100FE	R5F100GE	R5F100JE	R5F100LE	−	−	−
KB	−	Note 1	R5F101EE	R5F101FE	R5F101GE	R5F101JE	R5F101LE	−	−	−
48	4 KB	3 KB	R5F100ED	R5F100FD	R5F100GD	R5F100JD	R5F100LD	−	−	−
KB	−	3 KB	R5F101ED	R5F101FD	R5F101GD	R5F101JD	R5F101LD	−	−	−
32	4 KB	2 KB	R5F100EC	R5F100FC	R5F100GC	R5F100JC	R5F100LC	−	−	−
KB	−	2 KB	R5F101EC	R5F101FC	R5F101GC	R5F101JC	R5F101LC	−	−	−
16	4 KB	2 KB	R5F100EA	R5F100FA	R5F100GA	−	−	−	−	−
KB	−	2 KB	R5F101EA	R5F101FA	R5F101GA	−	−	−	−	−
