The PIC16(L)F1934/6/7 are described within this datasheet. They are available in 28/40/44-pin packages. Figure 1-1 shows a block diagram of the PIC16(L)F1934/6/7 devices. Table 1-2 shows the pinout descriptions. Reference Table 1-1 for peripherals available per device.
Peripheral | PIC16F193X | PIC16LF193X | |
ADC | ● | ● | |
Capacitive Sensing Module | ● | ● | |
Digital-to-Analog Converter (DAC) | ● | ● | |
EUSART | ● | ● | |
Fixed Voltage Reference (FVR) | ● | ● | |
LCD | ● | ● | |
SR Latch | ● | ● | |
Temperature Indicator | ● | ● | |
Capture/Compare/PWM Modules | |||
ECCP1 | ● | ● | |
ECCP2 | ● | ● | |
ECCP3 | ● | ● | |
CCP4 | ● | ● | |
CCP5 | ● | ● | |
Comparators | |||
C1 | ● | ● | |
C2 | ● | ● | |
Operational Amplifiers | |||
OPA1 | ● | ● | |
OPA2 | ● | ● | |
Master Synchronous Serial Ports | |||
MSSP1 | ● | ● | |
Timers | |||
Timer0 | ● | ● | |
Timer1 | ● | ● | |
Timer2 | ● | ● | |
Timer4 | ● | ● | |
Timer6 | ● | ● |
